Description
NEW FUNCTIONS, GREAT ADVANTAGES:
- Real-time graph of the sample temperature during each analysis
- Real-time graph of sample freezing point – OsmoTouch Osmometers
- An alphanumeric ID code can be added to each sample, easily
- Optional barcode reader for a quick sample identification (it requires an additional RS232 port to be requested when ordering)
- Results shown in different colours for a quick identification of anomalies or critical values
- Features in compliance with the FDA norm 21 CFR Part 11: set up of two different password levels (administrator and user), results with date,
- hour and username (electronic signature) and unmodifiable results to avoid any fraud
- Stable memory for 3 different calibration curves based on the favorite analytical ranges
- Stable memory for up to 4,000 results
- Easy download of test results to a USB pen drive
- Real time PC monitoring or quick download of test results to a PC thanks to CryoSoft Touch data handling software
- Immediate visualization of error messages
TECHNICAL CHARACTERISTICS:
- Sample capacity: single sample
- Full colour 7” touchscreen display
- Bath with Peltier cells controlled by software
- Operating ambient temperature: +5°C to 36°C
- Automatic calibration
- Lash and agitation width controlled by software
- Sample volume: from 50 to 200 μL
- Test duration: about 2-3 minutes/sample (from 0 to 900 mOsm/Kg)
- Warm-up time of the equipment: about 5 minutes
- Analytical range: from 0 to 3,000 mOsm/Kg
- Resolution: 1 mOsm/Kg
- Repeatability and reproducibility: ±2.5 mOsm/Kg (from 0 to 600 mOsm/Kg) or ±0.5% of the value (from 600 to 3,000 mOsm/Kg)
- USB port for data downloading to a pen drive
- 2 x RS232 ports for connecting the provided thermal printer and a PC
- An additional RS232 port can be added for connecting an optional barcode reader, upon request
- Power absorption: max. 150 W
- Dimensions: 285x485x360 mm (wxdxh, head down)
- Net weight: 16.1 Kg
